This product is Halal-compliant and has been certified by the American Halal Foundation (AHF) which complies with purity and cleanliness. By using a solvent-free acrylic adhesive, this double-sided tape minimizes odor and VOC emissions. *AHF: American Halal Foundation *VOC: Volatile Organic Compound
 AHF Certificate #: HP 6017 - CH |
 *Tape thickness is without release liner |
Unit: N/20mm
| Substrate | Adhesive Strength |
|---|---|
| Stainless steel | 14.8 |
| Aluminum | 13.8 |
| Acrylic | 15.0 |
| ABS | 14.5 |
| PP | 12.0 |
| PSt | 14.3 |
| Soft PVC | 15.0 |
| Glass | 10.3 |
| Polyethylene foam | 9.0 (foam breakdown) |
| Ester type urethane foam | 9.2 (foam breakdown) |
[Remarks]
| Product No. | Tape Thickness
[mm] |
Carrier | Adhesive | Adhesion Strength
[N/20mm] |
Points for selection |
|---|---|---|---|---|---|
| HL-512 | 0.15 | Non-woven | Acrylic | 14.80 | For metal, plastics and foams bonding. |
| HL-514 | 0.14 | Non-woven | Acrylic | 12.00 | For foam materials bonding. |
| HL-519 | 0.09 | Non-woven | Acrylic | 11.50 | When thin adhesive is needed. |
| HL-533 | 0.13 | PET | Acrylic | 12.50 | When die-cut process involved. |
