Double-coated Tape 5015ELE

Nitto double-coated tape 5015ELE consists of a non-woven tissue carrier, coated with a pressure sensitive acrylic adhesive with low emission values.

Used for a wide variety of mounting applications.

Download

Features

  • Reduced amount of VOC, formaldehyde, fogging and smell
  • Complies with VDA 278 (Fresenius Institute)
  • High adhesion on difficult to adhere materials e.g. low surfaces energy
  • High repulsion resistance
  • High heat resistance
  • Good workability
  • Recognition by imprint of the carrier
  • RoHS compliant

Structure

  1. Modified acrylic adhesive
  2. Non-woven tissue
  3. Modified acrylic adhesive
  4. PE-coated release liner

Properties

Typical value Test Method
Adhesive type Modified acrylic adhesive
Tape thickness* 0.160 mm EN 1942
Release liner type/colour Siliconised white PE-coated paper with green Nitto print (125 g/m²)
Carrier type Non-woven
Release Value 25 cN/50mm Nitto Test Method
Adhesion to BA steel 1400 cN/20mm EN 1939
Static shear 0.5 mm/3h EN 1943
Transport and storage conditions Temperature 15 to 30°C
Relative humidity 40 to 75% RH

* Tape thickness = Total thickness without liner
CAUTION: The above are typical values and should not be used in writing specifications.
Details from the test methods are described on the customer product specification.

Applications

Nitto 5015ELE is a double-coated pressure sensitive adhesive tape with low emission values used to mount different substrates in airtight places such as automotive interiors, electronic devices and houses. The tape is designed to make foams (PU, PE, PO, PP, etc.) self-adhesive.
Especially when they are exposed to severe stress, as in automotive applications.
This tape can also be used to bond graphic overlays, plastic plates and molds, surely if they have a low surface energy.
