Double-coated Tape D5318

Nitto double-coated tape D5318 is a polyester carrier based tape with an agressive modified acrylic adhesive used for mounting of different types of plastics.

Download

Datasheet

SDS

Datasheet

NBE_D5318_ENG

SDS

The information contained herein is based on all the documentation, information and data that can be obtained as of the date issued.

However, Nitto Denko Co., provides no warranties or guarantees, express or implied, regarding the accuracy or completeness of the information on contained amount, physical or/and chemical properties, and hazards or/and harm mentioned herein.

As for SDS of products categorized as "Article", Nitto Denko Co., voluntarily creates and releases the SDS for the particular products which frequently receive inquiries.

SDS_NBE_D5318_ENG

Features
Structure
Properties
Applications

Features

High adhesion on different plastics & rough surfaces
High temperature resistance
High holding power
Moisture stable liner
Easy processing
RoHS compliant

Structure

Acrylic adhesive
Polyester carrier
Acrylic adhesive
Release liner

Properties

Adhesive type	Pressure sensitive modified acrylic adhesive
Tape thickness	0,220 mm
Release liner	Siliconised white PE coated paper
Carrier type	White polyester
Adhesion value	2000 cN/20mm
Release value	30 cN/50mm
Static shear	1 mm/3h

Applications

Nitto D5318 is designed for mounting applications in sign and nameplate markets when white colour is needed. Nitto D5318 is a double-coated tape with a high adhesion level on different substrates such as plastics, low surface energy substrates, foams and metals. The tape is suitable for rough surface bonding.
The white PET carrier provides dimensional stability resulting in reduced elongation and
shrinkage. This tape provides the necessary opacity in order to reduce the amount of back printing operations.
