Double-coated Tape D5331

Nitto double coated polyester tape D5331 consists of a modified acrylic adhesive, coated on transparent polyester suitable for a variety of mounting applications.

Download

Features

  • Good adhesion on several substrates
  • Smooth coating surface
  • Dimensional stable liner
  • Available in sheets
  • RoHS compliant

Structure

  1. Acrylic adhesive
  2. Polyester carrier
  3. Acrylic adhesive
  4. Release liner

Properties

Adhesive type Pressure sensitive modified acrylic adhesive
Tape thickness 0,070 mm
Release liner Siliconised white PE coated paper
Carrier type Transparent polyester
Adhesion value 1200 cN/20mm
Release value 20 cN/50mm
Static shear 0,5 mm/3h

Applications

Nitto D5331 is a multi-purpose tape, typically used for nameplate & membrane switches assembly, thin metals and plastic decorative foils.
