Double Coated Tape 597B

Nitto transfer tapes 597B and 597N consist of a pressure sensitive modified acrylic adhesive.

The thin and smooth coating surface makes these tapes suitable for nameplate and graphic overlays applications.

Download

Features

  • High adhesion level
  • High cohesion
  • Thin and smooth coating surface
  • RoHS compliant

Structure

  1. Pressure sensitive acrylic-based adhesive
  2. Release liner

Properties

Adhesive type Pressure sensitive modified acrylic adhesive
Tape thickness 0.070 mm
Release liner Siliconised white Nitto paper
Carrier type Baseless
Adhesion value 1250 cN/20mm
Release value 15 cN/50mm
Static shear 1mm/2h

Applications

The tape is designed for mounting of a variety of substrates such as metal and plastic nameplates, films, textile labels, metal foils…
