Double-coated Tape 5015P

Nitto 5015P consists of a modified acrylic adhesive, coated on a 12 micron PET used as mounting tape on plastics and metals.

Download

Features

  • High adhesion on low surfaces energy substrates
  • Excellent ageing properties
  • Wide range of operating temperatures
  • Excellent repulsion resistance
  • Easy converting
  • High resistance to stress
  • RoHS compliant

Structure

  1. Acrylic adhesive
  2. Polyester carrier
  3. Acrylic adhesive
  4. Release liner

Properties

Adhesive type Pressure sensitive modified acrylic adhesive
Tape thickness 0,100 mm
Release liner Siliconised white PE coated paper
Carrier type Transparent polyester
Adhesion value 1600 cN/20mm
Release value 25 cN/50mm
Static shear 1,0 mm/3h

Applications

Nitto 5015P is a mounting tape for sealing materials such as foam and mesh which can be exposed to severe stress. The tape is used to bond graphic overlays, plastic plates and molds, surely if they have a low surface energy.
