Double-coated Tape D5318

Nitto double-coated tape D5318 is a polyester carrier based tape with an agressive modified acrylic adhesive used for mounting of different types of plastics.

Download

Features

  • High adhesion on different plastics & rough surfaces
  • High temperature resistance
  • High holding power
  • Moisture stable liner
  • Easy processing
  • RoHS compliant

Structure

  1. Acrylic adhesive
  2. Polyester carrier
  3. Acrylic adhesive
  4. Release liner

Properties

Adhesive type Pressure sensitive modified acrylic adhesive
Tape thickness 0,220 mm
Release liner Siliconised white PE coated paper
Carrier type White polyester
Adhesion value 2000 cN/20mm
Release value 30 cN/50mm
Static shear 1 mm/3h

Applications

Nitto D5318 is designed for mounting applications in sign and nameplate markets when white colour is needed. Nitto D5318 is a double-coated tape with a high adhesion level on different substrates such as plastics, low surface energy substrates, foams and metals. The tape is suitable for rough surface bonding.
The white PET carrier provides dimensional stability resulting in reduced elongation and
shrinkage. This tape provides the necessary opacity in order to reduce the amount of back printing operations.
