Double-coated Tape D5320

Nitto D5320 series are double-coated tapes with a polyester carrier coated with an aggressive acrylic adhesive used for mounting of different types of plastics.

Download

Features

  • Good adhesion on diffirent substrates & rough surfaces
  • High temperature resistance
  • High holding power
  • Easy processing
  • Bobbin shape
  • RoHS compliant

Structure

  1. Acrylic adhesive
  2. Polyester carrier
  3. Acrylic adhesive
  4. Release liner

Properties

Adhesive type Pressure sensitive modified acrylic adhesive
Tape thickness 0,180 mm
Release liner Siliconised red polypropylene
Carrier type Transparent polyester
Adhesion value 1700 cN/20mm
Release value 20 cN/50mm
Static shear 1 mm/3h

Applications

Nitto D5320 series are used for continuous long-run mounting application to a variety of decorative strips in furniture industry (trim mounting).

Suitable for mounting price information holders and plastic parts in sign & nameplate markets for marketing devices (Point Of Sales).
