Double-coated Tape D5952

Nitto tapes D5952 and D5952N consist of a pressure sensitive modified acrylic adhesive, intended for use as a general mounting tape where a particular high adhesion level is required.

Download

Features

  • Very high adhesion level
  • Good repulsion resistance
  • High temperature resistance
  • RoHS compliant

Structure

  1. Acrylic adhesive
  2. Release liner

Properties

Adhesive type Pressure sensitive modified acrylic adhesive
Tape thickness 0,080 mm
Release liner Siliconised havana paper
Carrier type Baseless
Adhesion value 2000 cN/20mm
Release value 30 cN/50mm
Static shear 1 mm/3h

Applications

Nitto D5952(N) is used for general assembly, especially on all varieties of foams used in automotive, building & construction and domestic appliance markets.
