Nitto D5331 is a high-performance double-coated tape featuring a transparent polyester carrier, coated on both sides with a modified acrylic adhesive.
It is suitable for a wide range of mounting applications, offering reliable adhesion across various substrates. The tape’s smooth adhesive surface ensures consistent bonding performance, while the release liner provides excellent dimensional stability for easy handling and precise converting.
 |
| Typical value* | Test Method | |
|---|---|---|
| Tape thickness** | 0.070 mm | EN 1942 |
| Adhesive type | Modified acrylic | n/a |
| Release liner type | Siliconized white PE coated paper (125g/m²) | n/a |
| Carrier type | PET (0.012mm) | n/a |
| Adhesion to BA steel | 1200 cN/20mm | EN 1939/ ISO 29862 |
| Adhesion to ABS | 1250 cN/20mm | EN 1939/ ISO 29862 |
| Adhesion to PP | 550 cN/20mm | EN 1939/ ISO 29862 |
| Static shear | 0.5 mm/3h | EN 1943 |
| Saft test | 185°C | +0.5°C/min, 20x15mm, 200g |
Nitto D5331 is a multipurpose tape, typically used for nameplate and membrane switches assembly, thin metals and plastic decorative foils.
