Double-coated Tape D53820B

Nitto D53820B is a lens mounting tape that consists out of a pressure sensitive adhesive and is used to mount plastic parts into electronic devices.

Download

Features

  • Good adhesion to metal and various plastics
  • Excellent "lens push-out" and "holding power" test
  • Low fogging (DIN 75201)
  • Easy processability
  • RoHS complaint

Structure

  1. Pressure sensitive acrylic adhesive
  2. Polyester carrier
  3. Pressure sensitive acrylic adhesive
  4. Release liner

Properties

Adhesive type Pressure sensitive acrylic adhesive
Tape thickness 0,200 mm
Release liner Paper (65g/m²)
Carrier type Black polyester (0.023 mm)
Adhesion value 1800 cN/20mm
Release value 15 cN/50mm
Static shear 1,0 mm/3h

Applications

Nitto D53820B is used for mounting of lenses onto mobile phones or for fixing parts for compact home appliances.
