Nitto 5359B is a high-performance double-coated tape featuring a black polyester carrier, coated on both sides with a modified acrylic adhesive.
Engineered for versatile mounting applications, it provides reliable adhesion across a wide range of substrates. The black PET carrier offers light shielding properties, making it suitable for applications requiring light blocking.
 |
| Typical value* | Test Method | |
|---|---|---|
| Tape thickness** | 0.050 mm | EN 1942 |
| Adhesive type | Modified acrylic | n/a |
| Release liner type | Siliconized Havana paper (90g/m²) | n/a |
| Carrier type | Black PET (0.012mm) | n/a |
| Adhesion to BA steel | 1000 cN/20mm | EN 1939/ ISO 29862 |
| Adhesion to AB | 1000 cN/20mm | EN 1939/ ISO 29862 |
| Adhesion to PP | 350 cN/20mm | EN 1939/ ISO 29862 |
| Static shear | 0.5 mm/3h | EN 1943 |
| Saft test | 185°C | +0.5°C/min, 20x15mm, 200g |
Nitto D5395B is used for mounting small foam parts in electric/ electronic equipment’s like mobile phones, ECU’s, office automation and domestic appliances. The product is designed for dust gasket mounting in mobile phones.
