Double-coated Tape D9600

Nitto D9600 is a double-coated tape with a flame retardant pressure sensitive modified acrylic adhesive and a PET carrier, intended for use as a general mounting tape where flame retardancy is required.

Download

Features

  • Flame retardant
  • Excellent holding power
  • High adhesion
  • Adheres to a wide variety of substrates
  • Easy processability
  • RoHS compliant

Structure

  1. Acrylic adhesive
  2. Polyester carrier
  3. Acrylic adhesive
  4. Release liner

Properties

Adhesive type Flame retardant modified acrylic adhesive
Tape thickness 0,100 mm
Release liner Siliconised white PE coated paper
Carrier type Transparent polyester
Adhesion value 1500 cN/20mm
Release value 20 cN/50mm
Static shear 1,0 mm/3h

Applications

Nitto D9600 is designed to make flame retardant materials self-adhesive such as decorative laminates and foams for applications in automotive, building and construction, shipbuilding and aerospace industries.
Flame retardancy must be evaluated in combination with the material on which it will be used.
