Nitto double coated tape D9600 is a PET carrier tape which consists of a flame-retardant pressure sensitive modified acrylic adhesive.
It's intended for use as a general mounting tape where flame retardancy is required.
 |
| Typical value* | Test Method | |
|---|---|---|
| Tape thickness** | 0.100 mm | EN 1942 |
| Adhesive type | Modified acrylic | n/a |
| Release liner type | Siliconized white PE coated paper (125g/m²) | n/a |
| Carrier type | PET (0.012mm) | n/a |
| Adhesion to BA steel | 1700 cN/20mm | EN 1939/ ISO 29862 |
| Adhesion to ABS | 1650 cN/20mm | EN 1939/ ISO 29862 |
| Adhesion to PP | 1250 cN/20mm | EN 1939/ ISO 29862 |
| Static shear | 1 mm/3h | EN 1943 |
| Saft test | 130°C | +0.5°C/min, 20x15mm, 200g |
Nitto D9600 is a high-performance PET carrier tape offering strong adhesion, thermal stability, and flame-retardant properties. It is engineered to make flame-retardant materials self-adhesive, including foams and decorative laminates, for use in automotive, marine, railway, aerospace, and building & construction applications. Flame retardance must be evaluated in combination with the material on which it will be used.
