Nitto Double Coated Tapes 597B and 597N are baseless tapes consisting of a pressure sensitive modified acrylic adhesive.
The thin adhesive coating makes these tapes suitable for nameplate and graphic overlay applications.
 |
| Typical value* | Test Method | |
|---|---|---|
| Tape thickness** | 0.070 mm | EN 1942 |
| Adhesive type | Modified acrylic | n/a |
| Release liner type |
597B: Siliconized white Nitto printed paper (90g/m²) 597N: Siliconized havana paper (90g/m²) |
n/a |
| Carrier type | Baseless | n/a |
| Adhesion to BA steel | 1295 cN/20mm | EN 1939/ ISO 29862 |
| Adhesion to ABS | 1200 cN/20mm | EN 1939/ ISO 29862 |
| Adhesion to PP | 555 cN/20mm | EEN 1939/ ISO 29862 |
| Static shear | 0.5 mm/3h | EN 1943 |
| Saft test | 100 °C | +0.5°C/min, 20x15mm, 200g |
Nitto 597B and 597N are designed with a thin adhesive coating, which provides a good cohesion to mount a variety of thin materials, such as metal and plastic nameplates, films, thin plastics, and foils.
