Nitto double-coated D5304 is a polyester carrier based tapes with an aggressive modified acrylic adhesive used for mounting of different types of plastics.
 |
| Tape Thickness* | 0.165 mm |
| Adhesive type | Colorless modified acrylic |
| Release liner type | D5304RD: Siliconised red polypropylene (0.07 mm)
D5304WH: Siliconised white polypropylene (0.07 mm) |
| Carrier type | Polyester (0.036 mm) |
| Adhesion to BA steel | 1800 cN/20mm |
| Release value | 20 cN/50 mm |
| Static shear | 1.0 mm/3h |
| Optimum transport and
storage conditions |
Temperature 5 °C to 35 °C
Relative humidity 40 to 85% RH |
* Tape thickness = Total thickness without liner
Details from the test methods are described on the customer product specification.
CAUTION: The above are typical values and should not be used in writing specifications.
Nitto D5304 is used for mounting decorative profiles in furniture industry (trim mounting), cable ducts. Suitable for mounting plastic parts in sign and nameplate markets for marketing devices (Point Of Sales).
