Nitto Double Coated Tapes 5015TPI - 5015TPI (DL) are baseless tapes consisting of pressure-sensitive modified acrylic adhesive.
It is designed for a wide range of mounting and bonding applications. They offer a well-balanced combination of adhesion, cohesion, and tack, ensuring excellent workability on various substrates, including those with low surface energy, while maintaining strong adhesive performance and reliable handling. The smooth coated surface allows for flexible and conformable applications.
 |
| Typical value* | Test Method | |
|---|---|---|
| Tape thickness** | 0.080 mm | EN 1942 |
| Adhesive type | Modified acrylic | n/a |
| Release liner type |
5015TPI: White PE coated paper (125 g/m²) 5015TPI(DL): White PE coated paper (125 g/m²) + PET liner (0.036mm) |
n/a |
| Carrier type | Baseless | n/a |
| Adhesion to BA steel | 1900 cN/20mm | EN 1939/ ISO 29862 |
| Adhesion to ABS | 1500 cN/20mm | EN 1939/ ISO 29862 |
| Adhesion to PP | 1300 cN/20mm | EN 1939/ ISO 29862 |
| Static shear | 1 mm/3h | EN 1943 |
| Saft test | 135°C | +0.5°C/min, 20x15mm, 200g |
Nitto 5015TPI and 5015TPI(DL) are versatile baseless tapes used for mounting and bonding on a variety of substrates across industries such as automotive, electronics, and appliance manufacturing. Its strong adhesion, high tack, and cohesive strength ensure reliable bonding on foams and plastics, including challenging low surface energy plastics. The tapes offer excellent resistance to repulsion and maintain stable performance over a broad range of temperatures. The thin and smooth coating surface allows flexible and conformable applications.
