This unique foam can be laminated with Nitto’s advanced adhesive technology to seal complex gaps against water, wind, dust, noise and heat.
 |
| 685C | Typical value* | Test Method |
|---|---|---|
| Thickness | 3 to 30 mm* | ISO 1923 |
| Density | 130 kg/m³ | ISO 845 |
| Elongation MD** | 600% | ISO 1798 |
| Tensile strength MD** | 125 kPa | ISO 1798 |
| 33% Compression Load | 6.9 kPa | Nitto Test Method |
| Water tightness (35%) | No leakage | Nitto U-shape *** |
| Chemical resistance | Stable | Immersion at 20 °C for 7 days |
| Test solution: acid (1%H2SO4) alkaline (1%NaOH), test performed on tensile strength and elongation acc. to ISO 1798. | ||
| Ozone resistance | No cracks | Visual inspection |
| Flammability (Ref 10mm) | < 100 mm/min | FMVSS 302 |
| Dimensional stability: 7 days at 70°C | ≤ 3% | ISO2796 |
| Product range | Double coated tape | Application |
|---|---|---|
| 685 | n/a | General purpose |
| 686 | Acrylic adhesive, non-woven carrier | General purpose |
| 686EP | Acrylic adhesive, non-woven carrier | High-end tape for low surface energy |
| 686P | Acrylic adhesive, PET carrier | Minimal stretch due to pet carrier |
| 686T | Acrylic adhesive, transfer tape | More flexibility (complex shape) |
| 687 | Butyl adhesive, cloth carrier | Greasy, rough and rubber base substrates |
| Complex | Typical Value | Test Method |
|---|---|---|
| Adhesion to 2B steel (90°) | ≥ 400 cN/20mm | EN 1939 |
| Watertightness (55%) | No leakage | Nitto U-shape *** |
| Flammability (Ref 10mm) | < 100 mm/min | FMVSS 302 |
| Temperature range |
General: -40°C to 135°C 687C: -40°C to 80°C |
n/a |
| In case of extreme temperatures, we recommend to perform application tests | ||
* Thicker material on request
** MD machine direction
*** Details from the test methods are described on the customer product specification.
EPT-Sealer 685 is specially designed to seal (complex) gaps against water, wind, dust, noise and heat. Depending on the application, the foam needs to be compressed by 50-80% to activate its sealing properties.
AUTOMOTIVE – sealing of HVAC unit, dashboard, air duct, firewall, battery.
HOME APPLIANCE – sealing refrigerators, dryers, washing machines.
NEW ENERGY – sealing of heat pumps, air-conditioners, EV chargers, solar panels.
