Nitto´s FIBERGUARD® S509H10P consists of a printed black and grey PE film with a special release coating and is coated with a pressure sensitive natural rubber-based adhesive with a high adhesion level.
The tape contributes to 30% bio-circular content certified by the ISCC+ mass balance approach.
 |
| Typical value* | Test Method | |
|---|---|---|
| Film type | PE film | n/a |
| Adhesive type | Rubber-based | n/a |
| Total thickness | 100µm | BTM019 |
| Adhesion on BA steel | 340 cN/25mm | ISO 29862 |
| Breaking strength MD** | 45 N/25mm | ISO 29864 |
| Elongation MD** | 350% | ISO 29864 |
| Weatherability on BA steel* | 100h | ISO 4892-2 |
| Color | Black and grey | n/a |
* The weatherability is measured on BA steel. Depending on the substrate the weatherability performance can be different.
CAUTION*: The above are typical values and should not be used in writing specifications.
** MD = Machine Direction
Details from the test methods are described on the customer product specification.
Nitto FIBERGUARD® S509H10P protects metal surfaces during both Fiber and CO2 laser cutting processes. It is ideal for high speed and performance laser cutting machines. Printed arrows allow you to install your metal in the appropriate direction after the laser cutting process. This will enable you to protect your substrate till the end of the supply chain, resulting in an optimum protection from scratches and impurities during various mechanical processes (bending, stamping, forming, etc).
